Kitchen Call Transmitter (TE-310)
SKU:TE-310- Wireless POCSAG Transmitter
- 50 backlit buttons, capable of pairing with 50 sets of pagers simultaneously
- Suitable for desktop or wall-mount installation
- Output power up to 1 watt
- D-Sub connector for programming
Description
Kitchen Call Transmitter (TE-310) is designed to assist you in enhancing internal communication and operational efficiency among your staff. TE-310 allows users to customize settings based on different needs, featuring 19 call buttons, including 16 calling buttons and 3 customizable group buttons. The Numeric Pager (AL-A01) is the optimal partner for TE-310. You can program it directly in any situation without the need for computer software. TE-310 boasts powerful functionality, a user-friendly interface, and durable, long-lasting features.
Suitable for various business sectors:
- Restaurants, lounges, bars, and coffee shops
- Hotels, resorts, and casinos
- Healthcare facilities (hospitals, doctor’s offices, nursing homes, patient or resident common areas, and waiting areas)
- Schools, colleges, and universities
- Automotive dealerships and service centers
Feel free to contact us, and we will provide you with the most suitable solution for your business needs. Explore more wireless equipment application videos.
Kitchen Call Transmitter (TE-310)– Product Description
- Wireless POCSAG Transmitter
- Friendly user interface
- 19 buttons with 16 name tags available
- Active Voltage Range: DC 9V/2.2A
- Output power up to 1 watt
- USB Type B for programming
- Range test
- F1, F2, F3 – three function keys for pre-programming canned message application
Additional information
Frequency | VHF 135~174 MHz, UHF 430~470 MHz |
---|---|
Modulation Type | FSK |
Channel Spacing | 12.5KHz, 25KHz |
Output Power | 1W |
Harmonic Radiation | 60 dBc or less -36dBm |
Frequency Stability | ±2.5 ppm at -10°C~+60°C |
Output Connect | BNC (F) |
Current Consumption | Standyby: 120mA; Transmit: 420mA |
Dimension | 232 (L) x 170 (W) x 50 (H) mm |
Weight | 650 g |
